SAAS Fuel Filter Water Separator 10 Microns | FS201

Special Order

FS201 - Fuel Filter Water Separator 10 Microns
The SAAS FS201 Fuel Water Separator is designed to ensure clean non water contaminated fuel is delivered to the engine. Fuel Water Separators provide effective protection for engines used in automotive, industrial, marine and recreational applications.

FILTER REMOVAL:

On the top of the filter housing there are 2 x hex nuts.
The smaller of the 2 has an 8mm head and retains the filter body.
The 8mm bolt passes all the way through the filter and into the plastic drain cock at the base below the inspection bowl.
Loosen off the 8mm bolt until it threads clear of the drain cock
Remove the drain cock
Remove the plastic inspection bowl
The filter is sealed by 2 o-ring gaskets
Ease the FS296 filter from the housing being careful not to damage the seals
Re-installation is the reversal - be careful not to over-tighten as this will cause pinching of the shaft o-ring seals and potential leakage
REPLACEMENT FILTERS:

The SAAS FS201 Fuel Water separator can be serviced with other popular fuel filters including:

CAV 7111-296
Cooper AZF015
Delphi HDF296
Lucas LFDE103
Ryco R2132P

FEATURES
Suits Diesel, Petrol and Pre-Mix fuel systems
Aids in the removal of water, moisture and solid contaminants
Protects injectors, rails, pumps and other components (depending on placement)
10 Micron filter for increased filtering
4 ports allow for LH or RH fuel line installation
Requires hose barb and blank off fitting kit
FS256 5/16" fuel line fitting kit
FS238 3/8" fuel line fitting kit
FS296 Replacement 10 micron filter
